SciAps X-50 CarCat+ XRF Analyser
Ask for a priceSpecification
- X-Ray Excitation Source: Compact X-ray tube with up to 40 kV Rh anode for alloy and precious metal excitation and optional 50 kV Au anode for expanded applications.
- Detector Type: 7 mm² Silicon Drift Detector (SDD) with high resolution (~170 eV FWHM at the Mn K-alpha line) for precise elemental detection.
- Elemental Analysis Range: Standard element suite covers a broad range including precious metals like Pt, Pd, Rh, Au, Ag plus transition and heavy metals; tailored CarCat+ app emphasizes catalytic converter metals.
- Display: 3.5-inch color capacitive touchscreen with Android-based user interface for intuitive operation and result visualization.
- Weight & Portability: Approximately 3.1 lbs (≈1.4 kg) including battery, making it lightweight and ergonomic for field use.
- Power Supply: Rechargeable Li-ion battery with internal and external charging options, and hot-swap capability (~60 s max).
- Data Connectivity: Built-in Wi-Fi, Bluetooth, and USB for real-time data transfer, reporting, and integration with PC software such as SciAps Profile Builder.
- Cameras: Integrated internal camera and macro camera for precise sample targeting and photo documentation of analyzed parts.
- Calibration & Software: Fundamental parameters calibration with external check standard for energy scale verification; CarCat+ specific app/library optimizes catalyst precious metal quantification.
- Environmental & Duty Range: Designed for field and shop use with operational support across typical industrial temperature ranges and rugged construction.
Description
SciAps X-50 CarCat+ XRF Analyser — Portable XRF Analyzer for Automotive Catalytic Converters
The SciAps X-50 CarCat+ is a handheld X-ray fluorescence (XRF) spectrometer specially designed for fast, reliable analysis of precious metals in automotive catalytic converters. Built on SciAps’s proven X-Series platform, this robust and ergonomic instrument delivers accurate elemental results in seconds, enabling recyclers, scrap dealers, and materials professionals to make confident decisions on-site.
Optimized for Precious Metal Analysis
The X-50 CarCat+ is calibrated to precisely quantify rhodium (Rh), platinum (Pt) and palladium (Pd) — the key precious metals present in converters — allowing accurate evaluation of catalyst value. Its XRF technology excites atoms with X-rays and measures the resulting fluorescence, giving direct elemental composition without sample preparation.
Reliable Instrumentation & Advanced Features
- Powerful X-ray Source: Tube capable of up to 50 kV, ideal for a broad range of catalytic materials.
- High-Performance Detector: Silicon Drift Detector (SDD) for improved sensitivity and resolution of precious metals.
- Built-In Touchscreen: Large, intuitive touchscreen interface running on Android makes operation simple and accessible.
- Dual Cameras: Integrated camera system for precise targeting and photo documentation — perfect for sample imaging and record keeping.
- Connectivity: Wi-Fi, Bluetooth and USB support for fast result transfer, reporting and integration with database software.
- Lightweight & Portable: Designed for easy mobility in scrap yards or workshops.
Performance & Efficiency
The X-50 CarCat+ provides rapid quantitative measurements of precious metals directly on catalytic converters, accelerating material valuation and streamlining recycling workflows. Operators can evaluate converters in seconds, improving throughput and reducing turnaround time.
kimet.ro
Applications
- Automotive Catalyst Recycling: Fast determination of Rh, Pt and Pd content for pricing and processing.
- Precious Metal Recovery: Accurate elemental analysis to support recovery and refining operations.
- Scrap Sorting & Valuation: On-site verification of converter types and metal content.
Why Choose SciAps X-50 CarCat+
The SciAps X-50 CarCat+ combines professional-grade XRF performance with portability, ease-of-use, and industry-focused calibration for automotive catalysts. Its fast, precise results and rugged design make it an essential tool for recyclers and precious metal specialists who need dependable analysis in demanding environments.
