Coating Thickness Gauge QNix 1500
Specification
-
Measuring range:
Fe: 0 - 5000 µm
NFe: 0 - 5000 µm -
Resolution:
0.1 μm up to 99.9 μm
1 μm from 100 to 999 μm
0.01 mm from 1.00 to 5.00 mm - Min. surface reqd. for measuring: 10 x 10 mm
-
Measuring principle:
Two magnetic measuring principles:
Fe: Magnetic-Flux/Hall Effect ref Fe
NFe: Eddy Current ref NFe
- Probe type: Integrated
-
Display Metric:
μm in measuring range 0 - 999 μm,
mm in measuring range 1.00 - 5,00 mm - Power supply: 9 V battery
- Dimensions: 166 x 64 x 34 mm
- Weight: 150 g, with battery
Description
Coating Thickness Gauge QNix 1500
An expert uses QNix® 1500. The classic among the coating thickness gauges – it is impossible hardly to imagine the automotive sector without it. As patented electronic coating thickness gauge with two independently working probes for steel and iron as well as non-metal substrates and a readable duplex LCD display, QNix® 1500 offers an unusually extensive spectrum of use. Extended measuring range up to 5000 µm. The flat design of this gauge allows for measurements at difficult-to-access points. Automobile experts around the globe appreciate this simple and flexible use, even at wide stretching surfaces. Automobile manufacturers and car body shops also put their trust in this gauge.
